At this time, the process statement proceeds through lines 12, 13, 14, and back to It is again suspended at line From the simulation waveform, it is easy to see that signal Q follows signal D with a delay. Whatever the value of signal D before the rising edge of the clock CLK, it is captured as the value of signal Q. This is the reason we often refer to a D flip-flop as a delay flip-flop. The D flip-flop has only one Q output; output Qn inverted Q is not connected.

A temporary signal DFF is declared in line 9, which is used in line Output signals Q and Qn are assigned in line The above D flip-flop is the simplest version. It does not have the synchronous or asynchronous reset input. Every target signal signals appearing on the left-hand side of the signal assignment state- ments affected by the rising edge expression infers a number of flip-flops depending on the target signal width.

Processes seqO lines 13 to 17 and seql lines 18 to 26 use a wait statement inside a process statement without a sensitivity list. The target signal to infer a flip- flop can have a Boolean expression on the right-hand side of the signal assignment statements as in lines 16, 24, and The target signal value can also be affected by other sequential statements such as the if statement in lines 21 to These Boolean expressions and sequential statements would result in combination circuits before the D input of the D flip-flop as shown in Figure synthesized schematic.

Processes seq2 lines 28 to 35 and seq3 lines 36 to 46 use a process statement with a sensi- 8 Chapter 2 VHDL and Digital Circuit Primitives tivity list. There is no wait statement inside the process statement.

Digital Systems Design with VHDL and Synthesis An Integrated Approach

As we recall, a process statement should have either a sensitivity list or at least a wait statement , but not both. SRSTn is used in lines 21, 26, 39, and 40 to show various ways to synchronously reset the flip-flops. The synchronous behavior is modeled by checking the rising edge before the SRSTn signal affects the target signal values.
